FF-5100 Non-cyanide Alkaline Copper Plating Chemicals for Fast Deposition and Stable Process in Electroplating

FF-5100  Non - cyanide alkaline copper plating process

FF-5100 Non - cyanide alkaline copper plating is environment friendly, which can meet the environmental requirements of the electroplating industry .

1. Features

1.1   Non-cyanide, suitable for direct copper plating for iron and steel substrate, also suitable for aluminum alloy and zinc alloy.

1.2   Has excellent dispersion and coverage, coating fine, smooth, soft and a certain brightness.

1.3   Single component supplement, simple operation , wide temperature range, can be at 40 ~ 50 ℃.

1.4   Coating surface is not hydrophobic, without removing the film, can be directly plated with nickel or other metals.

2. Solution composition and process parameters

2.1 Process Flow:

Pre-treatment → washing → washing → acide activation → washing →washing → copper plating(FF-5100) → Washing →  Post-processing

2.2 composition of plating solution
